The Automatic Tube Feeding Machine is supplied in a coil-strip feeding configuration for high-speed stamping lines. It serves the material-entry section of motor rotor, stator and EI-core production, supplying coiled metal strip to the downstream press feeder.
Category
Feeding Machine
Share to
Description

Product Overview



The Automatic Tube Feeding Machine is supplied in a coil-strip feeding configuration for high-speed stamping lines. It serves the material-entry section of motor rotor, stator and EI-core production, supplying coiled metal strip to the downstream press feeder.

product-1920-1080

Key Advantages





Dual-spindle 180-degree arrangement

Two spindles share a base arranged for 180-degree changeover. While one position supplies material, the second provides a standby coil position, moving coil preparation away from the empty-reel stage and shortening the physical exchange between successive coils.

0.1–3.0 mm strip-thickness range

The machine handles strip thicknesses from 0.1 to 3.0 mm. In stamping schedules that alternate thin electrical stock with heavier sheet, this gauge range accommodates successive coil materials at the pay-off stage without requiring a separate stand solely for each thickness.

Externally pulled reel with damping

The press feeder supplies the pulling force that rotates the reel. During intermittent strip demand, the damping device restrains residual reel motion between feed strokes, limiting extra strip payout when the pulling action pauses.

Four guided mandrel segments

Four segments are located by tapered dovetail grooves and radial sliding guides, with front bearing support for the mandrel. During repetitive coil payout, this arrangement constrains the segment path and supports the shaft at the front of the loaded reel.



product-1080-810

Custom Automatic Tube Feeding Machine

Yuanding designs and manufactures the Custom Automatic Tube Feeding Machine using your coil-strip specifications and stamping-line drawings. The coil-feeding assembly is produced with the project-specific mounting arrangement and selected coil-handling accessories.

Customizable Items

• Hydraulic expansion configuration

• Coil press arm

• Coil-loading trolley

• Mandrel working dimensions

• Machine mounting arrangement

• Colour and OEM identification

Key Specifications



Parameter

Specification

Power Type

Unpowered (external pull from high-speed press)

Material Thickness

0.1 – 3.0 mm

Spindle Design

Double spindle with 180° rotation

Operation Mode

Non-stop coil change

Core Expansion

Hydraulic with four segmented plates

Speed Compatibility

Up to 300+ strokes per minute



Quality Control





Incoming inspection checks the materials and purchased components against the manufacturing specification. Machined shafts and welded structures are inspected before final assembly.

The completed coil-feeding unit passes through final inspection and an operating trial. Factory acceptance is completed on the assembled machine before dispatch.

Third-party inspection is welcome. A full inspection before packing is available on request, with production images or video supplied during manufacture.



FAQ



Q: What payment terms do you offer?

A: Payment is 30% in advance and 70% as the balance.

Q: How are the main machine and small parts packed?

A: The main machine is shipped unboxed; small parts are packed in wooden cases.

Q: What actuates the mandrel expansion mechanism?

A: A rear-mounted rotary cylinder drives a central pull rod.

Q: How is the average required strip speed calculated?

A: Average speed in m/min equals feed length in mm × strokes per minute ÷ 1,000.
